Check box example: caption options

This example shows one way to use check boxes in a nondialog window. It also shows you what happens when these caption options are combined. It shows how to change a window style after it has been created. And finally it shows how to force the redrawing of a window frame.
Source file is wincaptn.asm.

Back to Win32 ASM Page.

First we take care of the main window and the application start and end.

.386
.model  flat

; If using TLINK32
don't include vclib.inc
include vclib.inc    ; Microsoft VC++ .lib link names

include win32hst.inc ; constants
structures
and entry names

public _start

.code
_start:

.data
align   4
wc      dd      CS_VREDRAW or CS_HREDRAW  ; style
dd      WndProc                   ; lpfnWndProc
dd      0
0                       ; cbClsExtra
cbWndExtra
dd      0                         ; hInstance
dd      0                         ; hIcon
dd      0                         ; hCursor
dd      COLOR_WINDOW+1            ; hbrBackground
dd      0                         ; lpszMenuName
dd      wndclsname                ; lpszClassName

wndclsname db 'winmain'
0

extrn   GetModuleHandle:near

.code
push    large 0         ; NULL string pointer means
call    GetModuleHandle ; get HINSTANCE/HMODULE of EXE file
mov     [wc.wc_hInstance]
eax

extrn   LoadIcon:near
LoadCursor:near

.code
push    large IDI_WINLOGO
push    large 0         ; hInstance
0 = stock icon
call    LoadIcon
mov     [wc.wc_hIcon]
eax

push    large IDC_ARROW
push    large 0         ; hInstance
0 = stock cursor
call    LoadCursor
mov     [wc.wc_hCursor]
eax

extrn   RegisterClass:near

.code
push    offset wc
call    RegisterClass

.data
align   4
cwargs   dd   0                  ; dwExStyle
dd   wndclsname         ; lpszClass
dd   wnd_title          ; lpszName
dd   WS_VISIBLE or WS_OVERLAPPED or WS_SYSMENU or WS_THICKFRAME \
or WS_MINIMIZEBOX or WS_MAXIMIZEBOX  ; style
dd   40                 ; x
dd   40                 ; y
dd   300                ; cx (width)
dd   110                ; cy (height)
dd   0                  ; hwndParent
dd   0                  ; hMenu
dd   0                  ; hInstance
dd   0                  ; lpCreateParams

wnd_title db 'Caption (title bar) styles'
0

extrn   CreateWindowEx:near

.code
sub     esp
48            ; allocate argument list
mov     esi
offset cwargs ; set block move source
mov     edi
esp           ; set block move destination
mov     ecx
12            ; number of arguments
rep movsd
mov     eax
[wc.wc_hInstance]
mov     [esp+40]
eax      ; set hInstance argument in stack
call    CreateWindowEx

extrn   GetMessage:near
DispatchMessage:near

.data
align   4
msgbuf MSG      <>

.code
msg_loop:
push    large 0         ; uMsgFilterMax
push    large 0         ; uMsgFilterMin
push    large 0         ; hWnd (filter)
0 = all windows
push    offset msgbuf   ; lpMsg
call    GetMessage      ; returns FALSE if WM_QUIT
or      eax
eax
jz      end_loop

push    offset msgbuf
call    DispatchMessage

jmp     msg_loop

end_loop:

extrn   ExitProcess:near

.code
push    large 0 ; (error) return code
call    ExitProcess

Next we define our test window. We explicitly add in the WS_CAPTION because we will use a copy of this style argument as a basis for style changes. It turns out that although an overlapped windows always creates a caption (title bar) the title bar can be removed after the window is created by changing the window style.
The window procedure for this window is DefWindowProc because no special message handling is required.

;
; the test display window
;
.data
align 4

testwnd dd 0

wc2     dd      CS_VREDRAW or CS_HREDRAW  ; style
dd      DefWindowProc             ; lpfnWndProc
dd      0
0                       ; cbClsExtra
cbWndExtra
dd      0                         ; hInstance
dd      0                         ; hIcon
dd      0                         ; hCursor
dd      COLOR_WINDOW+1            ; hbrBackground
dd      0                         ; lpszMenuName
dd      wndclsname2               ; lpszClassName

test     dd   0                  ; dwExStyle
dd   wndclsname2        ; lpszClass
dd   caption2           ; lpszName
dd   WS_VISIBLE or WS_OVERLAPPED or WS_CAPTION  ; style
dd   160                ; x
dd   160                ; y
dd   200                ; cx (width)
dd   200                ; cy (height)
dd   0                  ; hwndParent
dd   0                  ; hMenu
dd   0                  ; hInstance
dd   0                  ; lpCreateParams

wndclsname2 db 'testdisplay'
0
caption2 db 'Display test'
0

Now we define the check boxes which are defined as buttons. There is no WNDCLASS structure because the button class is already defined and registered. We will handle all of the important check box activity in the main window which is the parent (and container) of all these check boxes.

; this holds the style bits used to change
;   the style options of the test window
;
align   4

test_style dd 0

;
; control IDs for buttons
;
IDCTL_SYSMENU equ 101
IDCTL_SIZEBOX equ 102
IDCTL_MINBOX  equ 103
IDCTL_MAXBOX  equ 104
;
; Temporary CreateWindowEx argument list for the check box "button" windows
;
align   4

chkbox   dd   0                  ; dwExStyle
dd   btnclsname         ; lpszClass
dd   0                  ; lpszName
dd   WS_VISIBLE or WS_CHILD or BS_CHECKBOX  ; style
dd   0                  ; x
dd   0                  ; y
dd   0                  ; cx (width)
dd   0                  ; cy (height)
dd   0                  ; hwndParent
dd   0                  ; hMenu
dd   0                  ; hInstance
dd   0                  ; lpCreateParams

btnclsname  db 'button'
0        ; letter case doesn't matter
;
; option/button table
;
align 4

sysmenu dd WS_SYSMENU
sysmenu_str
10
10
250
15
IDCTL_SYSMENU
sizebox dd WS_THICKFRAME
sizebox_str
10
25
250
15
IDCTL_SIZEBOX
minbox  dd WS_MINIMIZEBOX
minbox_str
10
40
250
15
IDCTL_MINBOX
maxbox  dd WS_MAXIMIZEBOX
maxbox_str
10
55
250
15
IDCTL_MAXBOX
;
; button texts
;
sysmenu_str db 'WS_SYSMENU'
0
sizebox_str db 'WS_THICKFRAME/WM_SIZEBOX'
0
minbox_str  db 'WS_MINIMIZEBOX'
0
maxbox_str  db 'WS_MAXIMIZEBOX'
0

There is only one window procedure defined by us and that is the one for the main window the one with the check boxes in it. We start with the message dispatch and the "close application" command.

extrn   DefWindowProc:near

.code
WndProc:
mov     eax
[esp+4+4]           ; message ID
cmp     eax
WM_COMMAND          ; controls clicked
je      on_command
cmp     eax
WM_CREATE           ; window created
je      on_create
cmp     eax
WM_DESTROY          ; about to start window destruction
je      on_destroy
jmp     DefWindowProc           ; delegate other message processing


extrn   PostQuitMessage:near

on_destroy:
push    large 0
call    PostQuitMessage

xor     eax
eax
ret     16

We create the check boxes here as a response to WM_CREATE. At this time the main window has been created and there is a window handle for it. The handle is used to assign the window as parent to each check box which are created as a child window. A child window must be assigned a parent when it is created.
We also register the test window class here and create the test window.

;
; the main window
;
.data
align   4

mainwnd dd 0

.code
on_create:
mov     eax
[esp+4+0]  ; hwnd
mov     [mainwnd]
eax
mov     eax
[wc].wc_hInstance
mov     [wc2].wc_hInstance
eax
push    offset wc2
call    RegisterClass

push    esi
push    edi

mov     esi
offset test
mov     eax
[esi+12]            ; style argument
mov     [test_style]
eax        ; save original style
call    install_subwindow
mov     [testwnd]
eax


mov     esi
offset chkbox
mov     edi
offset sysmenu
call    install_chkbox

mov     esi
offset chkbox
mov     edi
offset sizebox
call    install_chkbox

mov     esi
offset chkbox
mov     edi
offset minbox
call    install_chkbox

mov     esi
offset chkbox
mov     edi
offset maxbox
call    install_chkbox

pop     edi
pop     esi

xor     eax
eax    ; signal a successful CREATE
ret     16
;
; Create chkbox
;
;       ESI = address of CreateWindowEx arguments
;       EDI = chkbox table entry
;
; Returns:
;
;       EAX = BUTTON handle
;
install_chkbox:
mov     eax
4[edi]
mov     [chkbox+8]
eax    ; lpszName
set window name = window text
mov     eax
8[edi]
mov     [chkbox+16]
eax   ; x
mov     eax
12[edi]
mov     [chkbox+20]
eax   ; y
mov     eax
16[edi]
mov     [chkbox+24]
eax   ; cx
mov     eax
20[edi]
mov     [chkbox+28]
eax   ; cy
mov     eax
24[edi]
mov     [chkbox+36]
eax   ; hMenu
ctl ID when WS_CHILD
call    install_subwindow
ret
;
; Create main window's subwindows
;
;       ESI = address of CreateWindowEx arguments
;
; Returns:
;
;       EAX = handle of subwindow
;
install_subwindow:
mov     eax
[mainwnd]
mov     [esi+32]
eax            ; hwndParent
make "mainbox" owner or parent
;   of new window
mov     eax
[wc].wc_hInstance   ; get instance
mov     [esi+40]
eax            ; set hInstance of window class
sub     esp
48    ; allocate args
mov     edi
esp
mov     ecx
12
rep movsd
call    CreateWindowEx
ret

This is where most of the work happens in response to WM_COMMAND. If the command is not a button (check box) command we quit. Otherwise we fetch the style option. Because the option is encoded in a single bit the option doubles as a bit mask.

extrn   SendMessage:near
extrn   SetWindowLong:near
extrn   RedrawWindow:near

on_command:
mov     eax
[esp+4+8]   ; wParam
mov     edx
[esp+4+12]  ; lParam
cmp     eax
(BN_CLICKED shl 16)+IDCTL_SYSMENU
je      select_sysmenu
cmp     eax
(BN_CLICKED shl 16)+IDCTL_SIZEBOX
je      select_sizebox
cmp     eax
(BN_CLICKED shl 16)+IDCTL_MINBOX
je      select_minbox
cmp     eax
(BN_CLICKED shl 16)+IDCTL_MAXBOX
je      select_maxbox
jmp     exit_on_command
;
; Get styles
;
select_sysmenu:
mov     ecx
[sysmenu]
jmp     toggle
select_sizebox:
mov     ecx
[sizebox]
jmp     toggle
select_minbox:
mov     ecx
[minbox]
jmp     toggle
select_maxbox:
mov     ecx
[maxbox]
jmp     toggle

Now we get and reset the check box state. Here we see that messages are the main means of transferring information to and from the controls.

toggle:
push    ecx             ; save style

push    edx             ; save ctl handle

push    large 0
push    large 0
push    large BM_GETCHECK
push    edx             ; ctl handle from lParam
call    SendMessage

pop     edx             ; retrieve ctl handle

xor     eax
1           ; toggle check state

push    large 0
push    eax             ; new check state
push    large BM_SETCHECK
push    edx             ; ctl handle
call    SendMessage

pop     ecx             ; retrieve style

Then we change the window style of our test window.

xor     [test_style]
ecx        ; toggle style bit
push    [test_style]            ; new style
push    large GWL_STYLE
push    [testwnd]               ; test window
call    SetWindowLong

Changing the window style does not cause a redrawing of the window. Without the following the test window doesn't change until it is selected. And the redraw is imperfect.
So we add this API call to force a redrawing of the test window without selecting it. The title bar is part of the frame .

push    large (RDW_FRAME+RDW_INVALIDATE+RDW_UPDATENOW)
push    large 0         ; update rectangle
push    large 0         ; update region (overrides rect)
push    [testwnd]       ; test window
call    RedrawWindow

exit_on_command:
xor     eax
eax    ; signal WM_COMMAND was processed
ret     16

end     _start
